Cadillac CT4-V I (2019-2024) batt pos volt 22 footwell accent lighting ctrl accent lighting ctrl Wiring diagram

ACCENT LIGHTING CTRL BATT POS VOLT 21 BATT POS VOLT 22 FOOTWELL ACCENT LIGHTING CTRL ACCENT LIGHTING CTRL BATT POS VOLT 40 BLK WIRE BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (RIGHT SIDE OF DASH) BRN/WHT WIRE CAN BUS (-) 2 SER DATA COMPUTER DATA LINES SYSTEM COURTESY LAMP CTRL DOME/READING LAMP CTRL DOME/READING LAMP ENABLE SIG DRIVER INFORMATION CENTER DISPLAY FRONT FLOOR CONSOLE COMPARTMENT LAMP GND 14 GRN/GRY WIRE GRN/VIO WIRE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES ILLUMINATION IND INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK INSTRUMENT PANEL LIGHT CONDUCTOR LAMP LEFT REAR FLOOR COURTESY LAMP LF DOOR OPEN SWITCH SIG LOGIC LR CHILD SECURITY LOCK REAR COMPARTMENT COURTESY LAMP RED/BLU WIRE RED/BRN WIRE RED/GRY WIRE RED/VIO WIRE RIGHT REAR FLOOR COURTESY LAMP RR CHILD SECURITY LOCK VIO/GRN WIRE VIO/GRY WIRE W/O WINDSHIELD HEAD-UP DISPLAY WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL/BLU WIRE
