Cadillac CT4-V I (2019-2024) backlight dimming ctrl 1 Wiring diagram
This page shows the only wiring diagram for the component.backlight dimming ctrl 1, which is found in the car Cadillac CT4-V I (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backlight dimming ctrl 1 (1 of 1)
BACKLIGHT DIMMING CTRL 1
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (RIGHT SIDE OF DASH)
CAN BUS (-) 2 SER DATA
COMPUTER DATA LINES SYSTEM
DIMMER SW LOW REF
DIMMER SWITCH
DIMMER SWITCH SIGNAL
DRIVER INFORMATION CENTER DISPLAY
GARAGE DOOR OPENER TRANSMITTER
GND 14
HAZARD WARNING SWITCH
HEAD-UP DISPLAY SWITCH
HOT AT ALL TIMES
ILLUMINATION IND
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LOGIC
ON/OFF VEHICLE SWITCH
POSITIVE VOLTAGE 40
RED/BLU WIRE
RED/VIO WIRE
W/O WINDSHIELD HEAD-UP DISPLAY
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component: -> Instrument illumination circuit (1 of 2) -> BACKLIGHT DIMMING CTRL 1
