Back-up lamps circuit for Cadillac Catera I (1996-2001)
Back-up lamps circuit
AUTOMATIC TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION HOUSING)
BLK WIRE
BLU WIRE
BRN WIRE
FLASHER FUSE 3
FUSE BLOCK (MOUNTED TO DASH, ON LOWER LEFT SIDE OF STEERING COLUMN)
GRY WIRE
HOT IN ON OR START
LEFT BACKUP LAMP
POWER MIRRORS SYSTEM (AUTOMATIC DAY/ NIGHT MIRROR)
RIGHT BACKUP LAMP
WHT/BLK WIRE
