Cadillac Catera I (1996-2001) vss output Wiring diagram
This page shows the only wiring diagram for the component.vss output, which is found in the car Cadillac Catera I (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vss output (1 of 1)
1 2 3 4 5 6 7 8 9 (KEY WORD 82) DATA (-)
1995 VFTC
BLK WIRE
BLK/GRY WIRE
BLK/PPL WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR (DLC)
FLASHER FUSE 3
FUSE BLOCK (MOUNTED TO DASH, ON LOWER LEFT SIDE OF STEERING COLUMN)
GROUND
HOT IN ON OR START
POWER STEERING CONTROL MODULE (UNDER LEFT SIDE OF DASH)
RED WIRE
VSS INPUT (+) IGNITION
VSS OUTPUT
WHT WIRE
Go to component -> Electronic power steering circuit -> VSS OUTPUT
