Cadillac Catera I (1996-2001) vss hi sig not used Wiring diagram

1-2, 3-4 SHFT 1-2, 3-4 SHIFT SOL 2-3 SHIFT SOL BAND APPLY SOL 61 45 8 CAN HIGH CAN LOW DATA AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION CONTROL INDICATOR AUTOMATIC TRANSMISSION CONTROL SELECTOR LEVER (SHIFT INTERLOCK ASSEMBLY) AUTOMATIC TRANSMISSION MALFUNCTION INDICATOR AUTOMATIC TRANSMISSION RANGE SWITCH (LEFT SIDE OF TRANSMISSION HOUSING) AUTOMATIC TRANSMISSION WINTER MODE SWITCH B+ B+ DIM CTRL TRANS A TRANS B TRANS C TRANS P BAND APPLY SOL PC SOL LO GROUND BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/PPL WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/PPL WIRE BRN/WHT WIRE CAN LOW CAN HIGH SERIAL DATA CLAMP 15 CRUISE FUSE 15 CLAMP 30 A/T FUSE 5 CLAMP 58 FUSE 26 CRUISE CONTROL, HEADLAMPS, POWER WINDOWS, SYSTEMS DATA LINK CONNECTOR (LEFT SIDE OF DASH) ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) FLASHER FUSE 3 FRONT SIDE MARKER LIGHTS, HEATER A/C CONTROL, LICENSE LAMPS, RADIO FUSE BLOCK (LEFT SIDE OF DASH) GRN WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HAZARD WARNING SWITCH, POWER STEERING CONTROL MODULE HOT AT ALL TIMES HOT IN ON OR START HOT W/ PARK LAMP RELAY ON IGNITION NOT USED ILLUM INSTRUMENT CLUSTER INTERIOR LIGHTS MAIN CASE ADAPTER CASE NCA WIRE ORG/BLK WIRE PC SOL HI POWER RELAY OUT PNK WIRE PRESSURE CONTROL SOL REAR SUSPENSION LEVELING AIR COMPRESSOR RELAY RED WIRE SPORT INDICATOR SPORT MODE CTRL SPORT MODE INPUT WINTER MODE SW VSS LO SIG VSS SHIELD GND SPORT MODE SWITCH TCC SOL TCC SOL CTRL 2-3 SHIFT TFT GROUND TFT SIG THIRD GEAR IND TRANS LIGHT CTRL TCM BATTERY FEED TRANS RANGE A TRANS RANGE C TRANS RANGE B TRANS RANGE P TRANSMISSION CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) TRANSMISSION FLUID TEMPERATURE SENSOR VSS HI SIG NOT USED WHT WIRE YEL WIRE
