Cadillac Catera I (1996-2001) set/accel signal Wiring diagram
This page shows the only wiring diagram for the component.set/accel signal, which is found in the car Cadillac Catera I (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram set/accel signal (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR (ON TOP OF ACCELERATOR PEDAL)
APP 1 SIGNAL
APP 2 SIGNAL
BLK/BRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLAMP 15 CRUISE FUSE 15
CLAMP 15 PBLS FUSE 2
CRUISE CONTROL RELEASE SWITCH (ATTACHED TO BRAKE PEDAL)
CRUISE CONTROL SWITCH
CRUISE IND
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE CONTROL SYSTEM
FUSE BLOCK
HOT AT ALL TIMES
HOT IN ON OR START
HZD FUSE 12
INSTRUMENT CLUSTER
NCA WIRE
OFF
RED WIRE
REF GROUND
RESUME/ DECEL
SET/ ACCEL
SET/ACCEL SIGNAL
STOPLIGHT SWITCH (ATTACHED TO BRAKE PEDAL)
THROTTLE POSITION SENSOR (ON THROTTLE BODY ASSEMBLY)
THROTTLE VALVE MTR -
TP SENSOR 1 SIGNAL
TP SENSOR 2 SIGNAL
WHT WIRE
Go to component -> Cruise control circuit -> SET/ACCEL SIGNAL
