Cadillac Catera I (1996-2001) serial data class 2 exterior lp power low power driver trunk release Wiring diagram

AIR CONDITIONING SYSTEM BATTERY GUARD DOORS LOCK BLK WIRE BLK/BRN WIRE BLK/PPL WIRE BLK/RED WIRE BODY CONTROL MODULE (BCM) (MOUNTED ON RIGHT "A" PILLAR, BEHIND TRIM PANEL) BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/PPL WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CLAMP W PBSL FUSE 24 DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF STEERING COLUMN) DOOR LOCKS SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM SHIFT INTERLOCK SYSTEM FAST WIPER INPUT TS DELAY INPUT TS RETURN INTERIOR LIGHTS ON/OFF FUEL LID UNLOCK WIPER 1 POS/INTERVAL TRUNK LIGHT FUSE 10 FUSE BLOCK (LOWER LEFT OF STEERING COLUMN) GEAR OUT OF PEAK POSITION (ALL) DOOR JAMB BATTERY POSITIVE VOLTAGE GRY WIRE HEADLIGHTS SYSTEM INSTRUMENT CLUSTER SYSTEM HOT AT ALL TIMES POWER DISTRIBUTION FUSE BLOCK (LEFT FRONT OF ENGINE COMPT) FUSE HOT IN RUN HOT IN RUN CLAMP 15 CRUISE FUSE 15 HOT W/ KEY IN IGNITION INTERIOR LIGHTS SYSTEM POWER WINDOWS SYSTEM POWER TOPS SYSTEM KEY-IN POSITIVE VOLTAGE CRANK POSITIVE VOLTAGE MULTI-FUNCTION RELAY (UNDER LEFT SIDE OF DASH) PARKLIGHT ON/OFF LO BEAM ON/OFF INPUT BRAKE SWITCH POWER DISTRIBUTION SYSTEM RADIO CELLULAR PHONE RED WIRE RED/WHT WIRE RED/YEL WIRE SERIAL DATA CLASS 2 EXTERIOR LP POWER LOW POWER DRIVER TRUNK RELEASE SHIFT INTERLOCK SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM WIPER/WASHER SYSTEM INTERIOR LIGHTS SYSTEM WHT WIRE YEL WIRE
