Cadillac Catera I (1996-2001) pump motor valve power output Wiring diagram

1 2 PUMP MTR CTRL RELAY 12 29 ABS CAN LO ABS CAN HI ABS FUSE 19 ANTILOCK BRAKE IND ASV 1 VALVE SOLENOID ASV 2 VALVE SOLENOID BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE PRESSURE MODULATOR VALVE (BPMV) BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/PPL WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE CAN INTERFACE LOW CAN INTERFACE HIGH TRACTION CONTROL SW CLAMP 15 CRUISE FUSE 15 DATA LINK CONNECTOR ELECTRONIC BRAKE/TRACTION CONTROL MODULE (EBTCM) (LOWER LEFT FRONT OF ENG COMPT) ELECTRONIC TRACTION CONTROL SWITCH ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) FUSE BLOCK GRY/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START HZD FUSE 12 INSTRUMENT CLUSTER LEFT FRONT INLET VALVE SOLENOID LEFT FRONT OUTLET VALVE SOLENOID LEFT FRONT WHEEL SPEED SENSOR LEFT REAR INLET VALVE SOLENOID LEFT REAR OUTLET VALVE SOLENOID LEFT REAR WHEEL SPEED SENSOR NCA WIRE POWER DISTRIBUTION FUSE BOX FUSE PUMP MOTOR VALVE POWER OUTPUT RED WIRE RIGHT FRONT INLET VALVE SOLENOID RIGHT FRONT OUTLET VALVE SOLENOID RIGHT FRONT WHEEL SPEED SENSOR RIGHT REAR WHEEL SPEED SENSOR RIGHT REAR INLET VALVE SOLENOID RIGHT REAR OUTLET VALVE SOLENOID RR SPEED SENS LO RR SPEED SENS HI SERIAL DATA STOP LAMP SW SIGNAL IGN GROUND B+ B+ GROUND TC INDICATOR ABS INDICATOR STOPLIGHT SWITCH (ATTACHED TO BRAKE PEDAL) TCS VALVE SOLENOID CONTROL SIGNALS TRACTION CONTROL IND USV 1 VALVE SOLENOID USV 2 VALVE SOLENOID VALVE SOLENOID CONTROL SIGNALS VSS
