Cadillac Catera I (1996-2001) lo lo int int Wiring diagram
This page shows the only wiring diagram for the component.lo lo int int, which is found in the car Cadillac Catera I (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lo lo int int (1 of 1)
BLK WIRE
BLK/PPL WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (BCM) (ON RIGHT "A" PILLAR)
BRN WIRE
BRN/YEL WIRE
CLAMP 15 FUSE 14
ECB
FUSE BLOCK (ON LOWER LEFT SIDE OF STEERING COL)
GAUGE CLUSTER
GRN WIRE
HI WIPER INPUT
HOT IN ON OR START
INT LO
INTERVAL SWITCH
LEFT WINDSHIELD WASHER NOZZLE
LO IN, INTERVAL
LO LO INT INT
MIST
OFF
OFF HI HI
RIGHT WINDSHIELD WASHER NOZZLE
SIDE OF DASH)
WHT WIRE
WINDSHIELD WASHER PUMP
WINDSHIELD WASHER SOLVENT LEVEL SWITCH
WINDSHIELD WIPER AND WASHER SWITCH
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER MOTOR RELAY (LEFT FRONT OF ENGINE COMPT)
WIPER FUSE 9
YEL WIRE
Go to component -> Wiper/washer circuit -> LO LO INT INT
