Cadillac Catera I (1996-2001) left outside rear view mirror Wiring diagrams
This page contains all the electrical diagrams for the component. left outside rear view mirror, in which he is found in the car Cadillac Catera I (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left outside rear view mirror (1 of 2)
AUTOMATIC TRANSMISSION CONTROL INDICATOR
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SWITCH
AUTOMATIC TRANSMISSION SHIFT LOCK/ UNLOCK SWITCH
AUTOMATIC TRANSMISSION WINTER MODE SWITCH
BLK WIRE
CD CHANGER
CELLULAR TELEPHONE RADIO
CIGARETTE LIGHTER (CONSOLE)
DATA LINK CONNECTOR
DRIVER SEAT HEATER RELAY PASSENGER SEAT HEATER RELAY
DRIVER SEAT HEATER SWITCH CIGARETTE LIGHTER (FRONT)
ELECTRONIC TRACTION CONTROL SWITCH
FROM HEATER AND A/C CONTROL (DIAGRAM 1 OF 2)
FUEL PUMP
FUEL TANK FILLER DOOR LOCK RELEASE SWITCH
GAUGE CLUSTER
HAZARD WARNING SWITCH
HEADLAMP SWITCH
HEATED OUTSIDE REAR VIEW MIRROR AND REAR WINDOW DEFOGGER RELAY
HORN RELAY
I/P COMPARTMENT LAMP SWITCH
INFLATABLE RESTRAINT STEERING WHEEL MODULE COIL
LEFT BACKUP LAMP AUXILIARY BRAKE LAMP MIDDLE TAILLAMP
LEFT FRONT SIDE DOOR LOCK SWITCH DOOR LOCK SWITCH
LEFT FRONT SIDE DOOR WINDOW REGULATOR MOTOR
LEFT OUTSIDE REAR VIEW MIRROR
LEFT REAR SEAT CUSHION HEATER
LEFT REAR SEAT CUSHION HEATER RELAY
LEFT REAR SIDE DOOR WINDOW REGULATOR MOTOR
LEFT REAR SIDE DOOR WINDOW SWITCH
LEFT STOP/ TAILLAMP
OUTSIDE REMOTE CONTROL REAR VIEW MIRROR SWITCH
PASSEN- GER SEAT HEATER SWITCH
RADIO SPEAKER AMPLIFIER SOUND PROCESSOR INTERFACE
REAR COMPARTMENT LID RELEASE SWITCH
REAR SUNSHADE MOTOR
RIGHT FRONT SIDE DOOR WINDOW REGULATOR MOTOR
RIGHT REAR SEAT CUSHION HEATER
RIGHT REAR SEAT CUSHION HEATER RELAY
RIGHT REAR SEAT HEATER SWITCH LEFT REAR SEAT HEATER SWITCH
RIGHT REAR SIDE DOOR WINDOW REGULATOR MOTOR
RIGHT REAR SIDE DOOR WINDOW SWITCH RIGHT FRONT SIDE DOOR WINDOW SWITCH
SPORT MODE SWITCH
THEFT DETERRENT MODULE
TRANSMISSION CONTROL SELECTOR SWITCH
TURN SIGNAL LAMP FLASHER
Go to component -> Ground distribution circuit (2 of 2) -> LEFT OUTSIDE REAR VIEW MIRROR
Wiring diagram left outside rear view mirror (2 of 2)
AIR CONDITIONING SYSTEM
BLK WIRE
BLK/BRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
DEFOGGER SYSTEM
DRIVER SEAT ADJUSTER MEMORY MODULE (ATTACHED TO UNDERSIDE OF DRIVER'S SEAT)
FUSE BLOCK
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT IN ON, BULB TEST OR START
INSIDE REAR VIEW MIRROR
LEFT OUTSIDE REAR VIEW MIRROR
LEFT RIGHT
O/S MIRROR FUSE 13
OUTSIDE REMOTE CONTROL REAR VIEW MIRROR SWITCH
RIGHT LEFT
RIGHT OUTSIDE REAR VIEW MIRROR
YEL WIRE
Go to component -> Memory seat & mirrors circuit (2 of 2) -> LEFT OUTSIDE REAR VIEW MIRROR
