Cadillac Catera I (1996-2001) left fog lamp Wiring diagram
This page shows the only wiring diagram for the component.left fog lamp, which is found in the car Cadillac Catera I (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left fog lamp (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLK/PPL WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BODY CONTROL MODULE (ON RIGHT "A" PILLAR)
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/PPL WIRE
BRN/RED WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLAMP 15 CRUISE FUSE 15
DAYTIME RUNNING LAMP RELAY
FLASH TO PASS SWITCH
FOG LAMP INDICATOR
FOG LAMP RELAY
FOG LAMP SWITCH
FUSE
FUSE BLOCK (LOWER LEFT SIDE OF STEERING COLUMN)
GRY/BLK WIRE
HEAD
HEADLAMP REQUIRED
HEADLAMP SWITCH
HEATER AND A/C CONTROL
HI BEAM LH FUSE 21
HI BEAM RH FUSE 32
HIGH BEAM
HIGH BEAM INDICATOR
HIGH BEAM SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
HOT WITH PARK LAMP RELAY ON
INSTRUMENT CLUSTER
LEFT FOG LAMP
LEFT HEADLAMP
LEFT HEADLAMP RELAY (HIGH BEAM)
LO BEAM LH FUSE 22
LO BEAM RH FUSE 31
LOW BEAM
LOW BEAM INDICATOR
LOW BEAM RELAY
MAX TWILIGHT SENTINEL DELAY SWITCH
MIN
MULTI-FUNCTION RELAY (UNDER LEFT SIDE OF DASH)
PARK LAMP RELAY
PARK OFF HEADLAMP SWITCH
POWER DISTRIBUTION FUSE BLOCK (LEFT FRONT OF ENGINE COMPT)
PRK LP LH FUSE 23
RADIO BATT GUARD FUSE 8
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY BOX (RIGHT SIDE OF STEERING COLUMN)
RIGHT FOG LAMP
RIGHT HEADLAMP
RIGHT HEADLAMP RELAY (HIGH BEAM)
SOLID STATE
TS DAY/NIGHT TS ON/OFF HI-BEAM ON/OFF EXT LAMP PWR
TURN SIGNAL SWITCH
TWILIGHT SENTINEL INDICATOR
TWILIGHT SENTINEL SWITCH
WHT WIRE
YEL WIRE
Go to component -> Headlight circuit -> LEFT FOG LAMP
