Cadillac Catera I (1996-2001) ignition key disarm unlock lock door jamb battery serial data ext lp power Wiring diagram

BLK WIRE BLK/BRN WIRE BLK/PPL WIRE BLU WIRE BLU/RED WIRE BODY CONTROL MODULE (MOUNTED ON THE RIGHT "A" PILLAR, BEHIND THE TRIM PANEL) BRN WIRE BRN/BLU WIRE BRN/PPL WIRE BRN/RED WIRE BRN/WHT WIRE BULB TEST CHECK ENGINE INDICATOR (MIL) CLAMP 15 CRUISE FUSE 15 COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR (DLC) (LOWER LEFT SIDE OF STEERING COLUMN) DOOR LOCK SWITCH ELECTRONIC BRAKE, TRACTION CONTROL MODULE ENGINE CONTROL MODULE (ON LEFT FRONT OF THE ENGINE COMPT, IN THE ECM HOUSING) FUSE BLOCK GAUGE CLUSTER GROUND HORN SECURITY IND LOW BEAM RLY PK LIGHTS OUT R/CMPT SW GROUND IGN SW SIG VSS THEFT DET OUT SERIAL DATA BATTERY GRY WIRE HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT IN ON, BULB TEST OR START HZD FUSE 12 IGNITION KEY DISARM UNLOCK LOCK DOOR JAMB BATTERY SERIAL DATA EXT LP POWER IGNITION SWITCH INSTRUMENT CLUSTER LEFT FRONT SIDE DOOR JAMB SWITCH LEFT FRONT SIDE DOOR LOCK SWITCH UN- LOCK LEFT REAR SIDE DOOR JAMB SWITCH RIGHT FRONT SIDE DOOR JAMB SWITCH LOCK MIL CTRL OFF POWER DISTRIBUTION FUSE BLOCK PPL REAR COMPARTMENT COURTESY LAMP SWITCH RED WIRE RED/WHT WIRE RIGHT FRONT SIDE DOOR LOCK SWITCH UN- LOCK LOCK RIGHT REAR SIDE DOOR JAMB SWITCH SECURITY INDICATOR SERIAL DATA THEFT DETERRENT MODULE (MOUNTED TO THE IGNITION LOCK CYLINDER) THEFT REQ SIG VSS OUT VSS/THEFT SIGNAL WHT WIRE XM 832 XM 834
