Cadillac Catera I (1996-2001) front height seat adjuster actuator motor Wiring diagrams

BACK DOWN FWD REAR HEIGHT BACK FWD BACK FWD REAR HEIGHT BLK WIRE DOWN DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT RECLINER ACTUATOR MOTOR ENTIRE SEAT FRONT HEIGHT FRONT HEIGHT SEAT ADJUSTER ACTUATOR MOTOR FUSE BLOCK HOT AT ALL TIMES NCA WIRE PASSENGER SEAT ADJUSTER SWITCH PASSENGER SEAT RECLINER ACTUATOR MOTOR PWR SEAT FUSE 35 REAR HEIGHT REAR HEIGHT BACK RED WIRE

1 2 3 4 5 6 7 BATTERY GROUND BATTERY IGNITION GROUND SERIAL DATA DOOR SW IN 1 2 GROUND POSITION IN 1.0 K 5 VOLTS BACK REST BACKWARD BACK REST FORWARD BLK WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/PNK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE CLAMP 15 CRUISE FUSE 15 DATA LINK CONNECTOR (LOWER LEFT SIDE OF STEERING COLUMN) DRIVER SEAT ADJUSTER MEMORY MODULE (ATTATCHED TO UNDERSIDE OF DRIVER'S SEAT) DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT RECLINER ACTUATOR MOTOR FORWARD/BACKWARD SEAT ADJUSTER ACTUATOR MOTOR FRONT HEIGHT SEAT ADJUSTER ACTUATOR MOTOR FUSE BLOCK GRY WIRE GRY/BRN WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT IN ON, BULB TEST OR START LEFT FRONT SIDE DOOR JAMB SWITCH MEMORY KEY MTR CONTROL NCA WIRE PERSONAL KEY 1 PERSONAL KEY 2 PERSONAL KEY 3 PWR SEAT FUSE 35 REAR HEIGHT SEAT ADJUSTER ACTUATOR MOTOR RED WIRE SEAT BACKWARD SEAT FOWARD SEAT FRONT HEIGHT DOWN SEAT FRONT HEIGHT UP SEAT REAR HEIGHT DOWN SEAT REAR HEIGHT UP
