Cadillac Catera I (1996-2001) clamp 15 a/t fuse 2 Wiring diagram
This page shows the only wiring diagram for the component.clamp 15 a/t fuse 2, which is found in the car Cadillac Catera I (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram clamp 15 a/t fuse 2 (1 of 1)
1995 VFTC
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SOLENOID
AUTOMATIC TRANSMISSION SHIFT LOCK CONTROL SWITCH
AUTOMATIC TRANSMISSION SHIFT LOCK UNLOCK SWITCH (OPEN IN PARK)
BLK WIRE
BLK/BRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BODY CONTROL MODULE (MOUNTED ON RIGHT "A" PILLAR) GEAR OUT OF PARK POSITION
BRAKE TO SHIFT INDICATOR
BRN WIRE
CLAMP 15 A/T FUSE 2
CLAMP 15 CRUISE FUSE 15
CLAMP W PBSL FUSE 24
FUSE BLOCK (LEFT SIDE OF STEERING COLUMN)
GRN WIRE
HOT IN ON OR START
HOT WITH KEY IN IGNITION
INSTRUMENT CLUSTER
LIFTING MAGNET (ATTACHED TO STEERING COLUMN)
NCA WIRE
RED WIRE
STOP LAMP SWITCH
STOP LAMP SWITCH (ON BRAKE PEDAL
TRANS- MISSION CONTROL SELECTOR SWITCH (ON TRANS- MISSION CONTROL LEVER)
TRUNK. TAILGATE, FUEL DOORS
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> CLAMP 15 A/T FUSE 2
