Cadillac Catera I (1996-2001) branch breakout, at base of left "a" pillar) Wiring diagram
This page shows the only wiring diagram for the component.branch breakout, at base of left "a" pillar), which is found in the car Cadillac Catera I (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram branch breakout, at base of left "a" pillar) (1 of 1)
1 2 3 4 5 6 BATTERY GROUND DR OPEN SIG SERIAL DATA IGNITION VSS
ANTI-THEFT SYSTEM
BLK WIRE
BLU WIRE
BLU/RED WIRE
BODY COMPUTER SYSTEM
BRANCH BREAKOUT, AT BASE OF LEFT "A" PILLAR)
BRN WIRE
BRN/WHT WIRE
CLAMP 15 CRUISE FUSE 15
FUSE BLOCK (MOUNTED TO DASH, ON LOWER LEFT SIDE OF STEERING COLUMN)
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT FRONT SIDE DOOR JAMB SWITCH
PPL
RED WIRE
SUN ROOF ACTUATOR (FRONT CENTER OF ROOF, ABOVE INSIDE REAR VIEW MIRROR)
SUN ROOF ACTUATOR MOTOR
SUN ROOF FUSE 25
VSS
WHT WIRE
Go to component -> Power top/sunroof circuits -> BRANCH BREAKOUT, AT BASE OF LEFT "A" PILLAR)
