Transfer case circuit for Cadillac ATS I (2012-2014)

Transfer case circuit

ATS Cadillac I (2012-2014): Transfer case circuit

Get access

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 OIL TEMP SENS SIG BATT POS VOLT GROUND BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION LOGIC CENTER DISPLAY INSTRUMENT PANEL CLUSTER (IPC) GRN WIRE HI SPD GMLAN SERIAL DATA HOT W/ IGNITION MAIN RELAY ENERGIZED IP BODY IGN FUSE LO SPD GMLAN SERIAL DATA NCA WIRE REAR BODY FUSE BLOCK RED/WHT WIRE TRANSFER CASE CLUTCH (INSIDE REAR OF TRANSFER CASE) TRANSFER CASE FLUID TEMPERATURE SENSOR (REAR OF TRANSFER CASE) TRANSFER CASE SHIFT CONTROL MODULE (FORWARD OF RIGHT REAR LAMP ASSEMBLY) UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) VIO WIRE VIO/GRY WIRE VIO/RED WIRE VIO/YEL WIRE WHT WIRE YEL/BLK WIRE YEL/WHT WIRE
