Driver"s memory seat circuit for Cadillac ATS I (2012-2014)

1 2 3 4 5 6 LOW SPEED GMLAN SERIAL DATA 1 2 B+ B+ BLK WIRE BLU WIRE BLU/VIO WIRE BLU/YEL WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT FRONT VERTICAL MOTOR DRIVER SEAT HORIZONTAL MOTOR DRIVER SEAT LUMBER/ BOLSTER PUMP DRIVER SEAT MEMORY CONTROL MODULE (ON DRIVER SEAT FRAME) DRIVER SEAT REAR VERTICAL MOTOR DRIVER SEAT RECLINE MOTOR DRVR PWR SEAT FUSE GRN WIRE GRN/BRN WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND GRY/BLU WIRE GRY/GRN WIRE HOT AT ALL TIMES LINEAR INT NETWORK BUS 8 MSM FUSE REAR BODY FUSE BLOCK (LEFT SIDE OF LUGGAGE COMPT) RED/WHT WIRE RED/YEL WIRE UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) VIO WIRE WHT/BLK WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE

BLK WIRE BLK/BLU WIRE BLU/GRN WIRE BLU/VIO WIRE BRN WIRE BRN/WHT WIRE DRIVER LEFT REAR SEAT HAPTIC MOVEMENT MOTOR DRIVER RIGHT REAR SEAT HAPTIC MOVEMENT MOTOR DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT MEMORY CONTROL MODULE (ON DRIVER SEAT FRAME) DRIVER SEAT MEMORY SWITCH GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRY/BLK WIRE GRY/BRN WIRE LUMBAR FORWARD SW SIG LUMBAR REARWARD SW SIG LUMBAR UP SW SIG LUMBAR DOWN SW SIG MEM MEMORY SEAT SWITCH SET SIG MEMORY SWITCH LOW REF MEMORY SEAT SWITCH SIGNAL NCA WIRE R VERTICAL MTR POS SENS SIG ST R MTR POS SNSR SIG RR MTR CTRL LR MTR CTRL RWD FWD RWD FWD UP SET- UP DN UP WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE
