Cadillac ATS I (2012-2014) w/ light sensitive rearview mirror Wiring diagram
This page shows the only wiring diagram for the component.w/ light sensitive rearview mirror, which is found in the car Cadillac ATS I (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ light sensitive rearview mirror (1 of 1)
BACKUP LAMP
BACKUP LAMP SPLY VOLT
BATT POS VOLT
BCM 6 FUSE
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BEHIND GLOVE BOX)
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENGINE CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT)
GRN WIRE
GRN/WHT WIRE
GROUND
GRY WIRE
HI SPD GMLAN SERIAL DATA
HOT AT ALL TIMES
INSIDE REARVIEW MIRROR
LOGIC
NCA WIRE
REARVIEW CAMERA (IF EQUIPPED)
RED WIRE
RED/WHT WIRE
SEAT AIR BAG (LEFT REAR) CONNECTOR BREAKOUT)
SERIAL SERIAL DATA DATA
SIG A
SIG B
SIG C
SIG P
TRANS PARK NEUTRAL SIG
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH AUTOMATIC TRANSMISSION ASSEMBLY
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT)
W/ LIGHT SENSITIVE REARVIEW MIRROR
W/O LIGHT SENSITIVE REARVIEW MIRROR
WHT WIRE
WHT/GRY WIRE
YEL WIRE
Go to component: -> Backup lamps circuit -> W/ LIGHT SENSITIVE REARVIEW MIRROR
