Cadillac ATS I (2012-2014) snrf sw data Wiring diagram

This page shows the only wiring diagram for the component.snrf sw data, which is found in the car Cadillac ATS I (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram snrf sw data (1 of 1)

Wiring diagram snrf sw data for Cadillac ATS I (2012-2014)

Get access

1 2 3 GND 9 10 LINEAR INTERCONNECT NETWORK BUS BATT POSITIVE VOLT BLK WIRE BLK/GRY WIRE BLU/PPL WIRE CLOSE COMPUTER DATA LINES SYSTEM EXPRESS CLOSE EXPRESS OPEN GRN/BRN WIRE HOT AT ALL TIMES LOGIC RED/GRY WIRE S/ROOF FUSE SNRF SW DATA SNRF SW LO REF SNRF VENT SW SIG SUNROOF MOTOR (FRONT CENTER OF ROOF) SUNROOF SWITCH UNDERHOOD FUSE BLOCK (RIGHT FRONT OF ENGINE COMPT) WHT/GRN WIRE YEL WIRE

Go to component: -> Power top/sunroof circuit -> SNRF SW DATA
