Cadillac ATS I (2012-2014) right front dome/ reading lamps Wiring diagrams
This page contains all the electrical diagrams for the component. right front dome/ reading lamps, in which he is found in the car Cadillac ATS I (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right front dome/ reading lamps (1 of 2)
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (BEHIND GLOVE BOX)
BRN WIRE
CHANNEL IN LEFT INSTRUMENT PANEL)
COMPUTER DATA LINES SYSTEM
CONTROL MODULE BREAKOUT)
COURTESY LAMP
DOME LAMP SWITCH
DRIVER DOOR COURTESY PASSENGER DOOR COURTESY
FUSE ENGINE COMPT)
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INADVERTENT PWR CTRL
INSTRUMENT ILLUMINATION CIRCUIT
INSTRUMENT PANEL COMPARTMENT LAMP
INSTRUMENT PANEL COMPARTMENT LAMP SWITCH
INTR LP CTRL
INTR LP DEFEAT SW SIG COURTESY LP SW SIG
LAMP LAMP
LED AMBIENT LIGHTING CTRL 1
LED AMBIENT LIGHTING CTRL 2
LEFT FRONT DOME/ READING LAMPS
LEFT SUNSHADE
LEFT SUNSHADE MIRROR LAMP
LIFT GATE AJAR SW SIG
MIRROR LAMP (RIGHT) BREAKOUT)
NCA WIRE
NETWORK BUS 3
NETWORK BUS 4
READING LAMPS (FRONT OVERHEAD CONSOLE) BREAKOUT)
REAR COMPARTMENT LID LATCH
RED/GRN WIRE
RIGHT FRONT DOME/ READING LAMPS
RIGHT INSTRUMENT PANEL
RIGHT SUNSHADE
RIGHT SUNSHADE MIRROR LAMP
TRUNK LP CTRL
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> RIGHT FRONT DOME/ READING LAMPS
Wiring diagram right front dome/ reading lamps (2 of 2)
6 SPEED A/T
BATTERY
BATTERY CURRENT SENSOR
BATTERY SAVER RELAY 1
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BRN WIRE
DATA LINK CONNECTOR
IGNITION MODE SWITCH
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INSIDE REARVIEW MIRROR
INSTRUMENT PANEL DIMMER SWITCH
LAMP SWITCH BREAKOUT)
LEFT FRONT DOME/ READING LAMPS
LEFT INSTRUMENT PANEL COURTESY LAMP
LEFT STEERING WHEEL CONTROLS SWITCH
LEFT SUNSHADE
NCA WIRE
OVERHEAD CONSOLE ACCENT LAMP
REAR COMPARTMENT COURTESY LAMP
RED WIRE
RED/ BLK WIRE
RETAINED ACCESSORY POWER RELAY
RIGHT FRONT DOME/ READING LAMPS
RIGHT REAR WINDOW DEFOGGER NOISE FILTER
RIGHT STEERING WHEEL CONTROLS SWITCH
RIGHT SUNSHADE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL ANGLE SENSOR
STEERING WHEEL HEATER
STEERING WHEEL HEATING CONTROL MODULE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ HEATED STEERING WHEEL
Go to component -> Ground distribution circuit (3 of 7) -> RIGHT FRONT DOME/ READING LAMPS
