Cadillac ATS I (2012-2014) retained accessory wiring diagram
This page shows the only wiring diagram for the component.retained accessory, which is found in the car Cadillac ATS I (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
retained accessory wiring diagram (1 of 1)
A/T
APO 1 FUSE
APO 2 FUSE
BATT FUSE
BLK WIRE
BLOWER MOTOR
CENTER CONSOLE ACCESSORY POWER RECEPTACLE
CHANNEL IN LEFT INSTRUMENT PANEL)
DATA LINK CONNECTOR
DISPLY FUSE
DLC FUSE
ESCL FUSE
FROM AUXILIARY UNDERHOOD FUSE BLOCK (DIAGRAM 1 OF 6)
FRT HVAC BLWR FUSE
GRY/VIO WIRE
HEADUP DISPLAY (IF EQUIPPED)
HVAC CONTROL MODULE
HVAC CONTROL MODULE (W/ START/ STOP SYSTEM)
HVAC/ CNTRL FUSE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INFO DISPLAY MODULE
INSTRUMENT CLUSTER
INSTRUMENT PANEL ACCESSORY POWER RECEPTACLE
JXXX
LEFT STEERING WHEEL CONTROL SWITCH
PASSENGER PRESENCE MODULE
POWER RELAY
PPL
RAP RELAY FUSE
RDO/HVAC FUSE
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
RETAINED ACCESSORY
RIGHT STEERING WHEEL CONTROL SWITCH
SDM/AOS FUSE
STEERING COLUMN LOCK MODULE (IF EQUIPPED)
STEERING WHEEL AIR BAG COIL
STR WHL CNTRL FUSE
TO BODY CONTROL MODULE (DIAGRAM 6 OF 6)
TRANSMISSION SHIFT LEVER POSITION INDICATOR
W/O START STOP SYSTEM W/ START/ STOP SYSTEM
Go to component -> Power distribution circuit (4 of 6) -> RETAINED ACCESSORY
