Cadillac ATS I (2012-2014) panel) vehicle stability control switch wiring diagram
This page shows the only wiring diagram for the component.panel) vehicle stability control switch, which is found in the car Cadillac ATS I (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
panel) vehicle stability control switch wiring diagram (1 of 1)
A/T
ABS BRAKE VSC VSC OFF IND IND IND IND
BATT POSITIVE VOLT
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/VIO WIRE
BRAKE BOOSTER VACUUM SENSOR (ON BRAKE BOOSTER)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DATA - DATA COM
DISPLY FUSE
DRIVER INFORMATION CENTER DISPLAY
FUSE BLOCK (LEFT SIDE OF INSTRUMENT PANEL)
GRN/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL
LOGIC
M/T
MOST MOST SERIAL SERIAL DATA (+) DATA (-)
PANEL) VEHICLE STABILITY CONTROL SWITCH
PARK BRAKE CONTROL SWITCH
RED/BLU WIRE
SPY VOL
SW SIGNAL VOL REF RELEASE SW SIG APPLY SW SIG VOL REF
SYSTEM SYSTEM
TRACTION CONTROL SWITCH
TRACTION OFF IND
W/ STOP/ W/O STOP/
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Anti-lock brakes circuit (2 of 3) -> PANEL) VEHICLE STABILITY CONTROL SWITCH
