Cadillac ATS I (2012-2014) left temperature up switch left temperature down switch wiring diagram
This page shows the only wiring diagram for the component.left temperature up switch left temperature down switch, which is found in the car Cadillac ATS I (2012-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left temperature up switch left temperature down switch wiring diagram (1 of 1)
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR SOLENOID VALVE A/C COMPRESSOR
AMBIENT LIGHT/SUNLOAD SENSOR (UPPER CENTER OF THE INSTRUMENT PANEL)
ANTI-THEFT SYSTEM HEADLIGHTS SYSTEM
AUTO A/C SWITCH
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
FAN DOWN VENTILATING SWITCH FAN UP VENTILATING SWITCH
GRN WIRE
GRN/WHT WIRE
GRY WIRE
LEFT TEMPERATURE UP SWITCH LEFT TEMPERATURE DOWN SWITCH
LOGIC
NCA WIRE
RADIO/HVAC CONTROLS
REAR DEFROST IND
REAR DEFROST SWITCH
RECIR- CULATION SWITCH
RED/PPL WIRE
RIGHT TEMPERATURE UP SWITCH RIGHT TEMPERATURE DOWN SWITCH
VIO/GRY WIRE
W/ ONSTAR
W/O ONSTAR
WHT/BLU WIRE
Go to component -> Automatic a/c circuit (2 of 4) -> LEFT TEMPERATURE UP SWITCH LEFT TEMPERATURE DOWN SWITCH
