Cadillac ATS I (2012-2014) left front dome/ reading lamps Wiring diagrams
This page contains all the electrical diagrams for the component. left front dome/ reading lamps, in which he is found in the car Cadillac ATS I (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left front dome/ reading lamps wiring diagram (1 of 2)
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (BEHIND GLOVE BOX)
BRN WIRE
CHANNEL IN LEFT INSTRUMENT PANEL)
COMPUTER DATA LINES SYSTEM
CONTROL MODULE BREAKOUT)
COURTESY LAMP
DOME LAMP SWITCH
DRIVER DOOR COURTESY PASSENGER DOOR COURTESY
FUSE ENGINE COMPT)
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INADVERTENT PWR CTRL
INSTRUMENT ILLUMINATION CIRCUIT
INSTRUMENT PANEL COMPARTMENT LAMP
INSTRUMENT PANEL COMPARTMENT LAMP SWITCH
INTR LP CTRL
INTR LP DEFEAT SW SIG COURTESY LP SW SIG
LAMP LAMP
LED AMBIENT LIGHTING CTRL 1
LED AMBIENT LIGHTING CTRL 2
LEFT FRONT DOME/ READING LAMPS
LEFT SUNSHADE
LEFT SUNSHADE MIRROR LAMP
LIFT GATE AJAR SW SIG
MIRROR LAMP (RIGHT) BREAKOUT)
NCA WIRE
NETWORK BUS 3
NETWORK BUS 4
READING LAMPS (FRONT OVERHEAD CONSOLE) BREAKOUT)
REAR COMPARTMENT LID LATCH
RED/GRN WIRE
RIGHT FRONT DOME/ READING LAMPS
RIGHT INSTRUMENT PANEL
RIGHT SUNSHADE
RIGHT SUNSHADE MIRROR LAMP
TRUNK LP CTRL
UNDERHOOD FUSE BLOCK (RIGHT FRONT OF
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> LEFT FRONT DOME/ READING LAMPS
