Cadillac ATS I (2012-2014) cru ctrl set/coast/ res/acc sw sig adap cru ctrl gap up/dwn sw sig Wiring diagram

12 VOLT REF 18 19 NEU GEAR SENS SUPPLY NEU GEAR SENS RETURN 34 54 70 16 32 73 TP SENS 5 VOLT REFR TP SENS LOW REF 5380 (OR 6111) 5381 (OR 6109) 5382 (OR 6110) 7 13 BRK APPLY SENS SIG BRK APPLY SENS SPLY VOLT A/T M/T ACCELERATOR PEDAL POSITION SENSOR (ON ACCELERATOR PEDAL) APP SIG (2) APP LOW REF (2) APP LOW REF (1) APP SIG (1) BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BODY CONTROL MODULE (BEHIND GLOVE BOX) BRK POSITION SENS SIG CLUTCH APPLY SENS SIGNAL BRN/LT GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM CRU CTRL SET/COAST/ RES/ACC SW SIG ADAP CRU CTRL GAP UP/DWN SW SIG CRUISE/ETC/TCC BRK SIG ECM BATT FUSE ENGINE CONTROL MODULE (RIGHT FRONT OF ENGINE COMPT) GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY/BLK WIRE GRY/LT GRN WIRE HOT AT ALL TIMES LOGIC NEU GEAR SENS SIG (1) O/P SPD (DIGITAL) SIG REAR COMPARTMENT FUSE BLOCK (LEFT SIDE OF LUGGAGE COMPT) RED/BRN WIRE TAC MTR CTRL CLSE TAC MTR CTRL OPN GROUND THROTTLE BODY (FRONT OF ENGINE) TRANSMISSION OUTPUT SHAFT SPEED SENSOR (M/T) (RIGHT REAR OF TRANSMISSION) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/WHT WIRE
