Cadillac ATS I (2012-2014) cellular phone microphone Wiring diagrams
This page contains all the electrical diagrams for the component. cellular phone microphone, in which he is found in the car Cadillac ATS I (2012-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
cellular phone microphone wiring diagram (1 of 2)
AUDIO SIG +
BATT POS VOLT
BLK WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
CAMERA SIGNAL -
CELLULAR PHONE MICROPHONE
CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA
COAX
COMMUNICATION ENABLE
COMPUTER DATA LINES SYSTEM
DRAIN WIRE
GMLAN SERIAL DATA
GPS
GPS/CELL
GRN/WHT WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HUMAN INTERFACE CONTROL MODULE (BEHIND GLOVE BOX)
LOW REF
MICROPHONE/AUDIO
MOST CONTROL
MOST SERIAL DATA (+)
NAVIGATION ANTENNA SIGNAL SPLITTER
NAVIGATION DISPLAY SIG
NAVIGATION SYSTEM
NCA WIRE
NETWORK BUS 5
RED WIRE
RED/VIO WIRE
SER DATA
SIGNAL GROUND
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
USB RECEPTACLE
USB SRL DATA LOW REF
VOICE SIG
W/ NAVIGATION VEHICLE SYSTEM
W/ ONSTAR
W/O NAVIGATION VEHICLE SYSTEM
W/O ONSTAR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Navigation circuit, w/ touch screen & color information display (2 of 5) -> CELLULAR PHONE MICROPHONE
cellular phone microphone wiring diagram (2 of 2)
AUDIO SIG +
BATT POS VOLT
BLK WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BLU WIRE
CAMERA SIGNAL -
CELLULAR PHONE MICROPHONE
CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA
COAX
COMMUNICATION ENABLE
COMPUTER DATA LINES SYSTEM
DRAIN WIRE
GMLAN SERIAL DATA
GPS
GPS/CELL
GRN/WHT WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HUMAN INTERFACE CONTROL MODULE (BEHIND GLOVE BOX)
LOW REF
MICROPHONE/AUDIO
MOST CONTROL
MOST SERIAL DATA (+)
NAVIGATION ANTENNA SIGNAL SPLITTER
NAVIGATION DISPLAY SIG
NAVIGATION SYSTEM
NCA WIRE
NETWORK BUS 5
RED WIRE
RED/VIO WIRE
SER DATA
SIGNAL GROUND
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
USB RECEPTACLE
USB SRL DATA LOW REF
VOICE SIG
W/ NAVIGATION VEHICLE SYSTEM W/O NAVIGATION VEHICLE SYSTEM
W/ ONSTAR
W/O ONSTAR
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Radio circuit, w/ touch screen & color information display (2 of 5) -> CELLULAR PHONE MICROPHONE
