Buick Skylark VII (1992-1998) left/right motor drive unit Wiring diagram
This page shows the only wiring diagram for the component.left/right motor drive unit, which is found in the car Buick Skylark VII (1992-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left/right motor drive unit (1 of 1)
1995 VFTC
BATTERY
BLK WIRE
BRN WIRE
CONVENIENCE CENTER (LEFT OF STEERING COLUMN BEHIND I/P)
DOWN
DRIVE UNIT
GRN WIRE
LEFT
LEFT OUTSIDE MIRROR
LEFT/RIGHT MOTOR
LEFT/RIGHT MOTOR DRIVE UNIT
LT BLU WIRE
MIRROR CONTROL SWITCH
MIRROR SELECT SWITCH
MULTI-FUNCTION ALARM MODULE
NCA WIRE
ORG/ WIRE
OUTSIDE MIRROR SWITCH
RED WIRE
RIGHT
RIGHT OUTSIDE MIRROR
SWITCHED BATTERY
UP DOWN
UP/DOWN MOTOR
WHT WIRE
YEL WIRE
Go to component -> Power mirror circuit -> LEFT/RIGHT MOTOR DRIVE UNIT
