Buick Roadmaster VIII (1991-1996) rear window wiper/ washer, multi- function switch (wagon) wiring diagram
This page shows the only wiring diagram for the component.rear window wiper/ washer, multi- function switch (wagon), which is found in the car Buick Roadmaster VIII (1991-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear window wiper/ washer, multi- function switch (wagon) wiring diagram (1 of 1)
ANALOG DIM
ASHTRAY LAMP
AUTO HEADLAMP OR DRL CONTROL MODULE
BASE
BLK WIRE
BRN WIRE
COURTESY LAMPS CIRCUIT
COURTESY SWITCH
DIMMING SWITCH
DK BLU WIRE
GRY WIRE
HEAD OFF PARK
HEADLAMP SWITCH
HEADLIGHT SWITCH
HEATER AND A/C CONTROL
HOT AT ALL TIMES
I/P FUSE BLOCK (LEFT SIDE OF I/P)
INSTRUMENT CLUSTER
INT DIM FUSE 42
LEFT DOOR LOCK SWITCH LAMP
MAX
OPENS AT EXTREME POSITION
RADIO
REAR WINDOW WIPER/ WASHER, MULTI- FUNCTION SWITCH (WAGON)
RIGHT DOOR LOCK SWITCH LAMP
TRUNK LID RELEASE SWITCH
WHT WIRE
WITH DRL OR TWILIGHT SENTINEL
YEL WIRE
Go to component -> Instrument illumination circuit -> REAR WINDOW WIPER/ WASHER, MULTI- FUNCTION SWITCH (WAGON)
