Buick Roadmaster VIII (1991-1996) accessory switch panel Wiring diagrams
This page contains all the electrical diagrams for the component. accessory switch panel, in which he is found in the car Buick Roadmaster VIII (1991-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
accessory switch panel wiring diagram (1 of 2)
ACCESSORY SWITCH PANEL
BLK WIRE
FUSE BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ACCY OR RUN
LIFTGATE WIPER LATCH SWITCH
OFF
OFF ON ON
ORG/ WIRE
PARK
REAR WINDOW WIPER MOTOR
REAR WINDOW WIPER/ WASHER AND MULTI- FUNCTION SWITCH
REAR WIPER WASHER MOTOR (ON WASHER RESERVOIR)
RR WIPER FUSE #8
RUN WIRE
SOLID STATE
TRK P/DOWN FUSE #36
WASH
WIPE
YEL WIRE
Go to component -> Rear washer/wiper circuit -> ACCESSORY SWITCH PANEL
accessory switch panel wiring diagram (2 of 2)
Go to component -> Trunk release circuit, without keyless entry -> ACCESSORY SWITCH PANEL
