Buick Rendezvous I (2001-2007) vss signal Wiring diagram
This page shows the only wiring diagram for the component.vss signal, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vss signal (1 of 1)
BACK-UP LPS RELAY
BLK WIRE
BODY CONTROL MODULE (IN CONSOLE, ABOVE FUSE BLOCK, IN CENTER CONSOLE)
BRN WIRE
CENTER AMBER IND CTRL LEFT AMBER IND CTRL
CENTER AMBER INDICATOR
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROLS SYSTEM
FUSE 26
GROUND B+ PARK ASSIST SW SIG BACKUP LAMP VOLTAGE DIAGNOSTIC INPUT PNK WIRE
GRY WIRE
HOT IN RUN OR START
I/P SWITCH ASSEMBLY
INDICATOR
LEFT AMBER INDICATOR
LEFT REAR CORNER OBJECT SENSOR (BEHIND LEFT CORNER OF REAR BUMPER)
LEFT REAR MIDDLE OBJECT SENSOR (BEHIND MIDDLE OF REAR BUMPER)
LOW REF
LT BLU WIRE
LT GRN WIRE
MIRRORS SYSTEM
ORG/ WIRE
PARK AID
PNK WIRE
POWER DISTRIBUTION SYSTEM
REAR PARK CHIME SIG TELLTAIL ASSY VOLTAGE
REAR PARKING ASSIST (RPA) DIAGNOSTIC CONNECTOR
REAR PARKING ASSIST (RPA) DISPLAY
REAR PARKING ASSIST (RPA) MODULE (BEHIND FRONT CENTER DASH CONSOLE)
RED IND CTRL WIRE
RED WIRE
RIGHT REAR CORNER OBJECT SENSOR (BEHIND RIGHT CORNER OF REAR BUMPER)
RIGHT REAR MIDDLE OBJECT SENSOR (BEHIND MIDDLE OF REAR BUMPER)
SENSOR SIGNAL
SPLICE
SPLICE PACK
SUPPLY VOLTAGE
TRNSIG FUSE 19
UNDERHOOD FUSE BLOCK (FRONT OF RIGHT WHEELHOUSE, ABOVE BATTERY) AWD FUSE 30
VSS SIGNAL
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit -> VSS SIGNAL
