Buick Rendezvous I (2001-2007) trac on/off switch Wiring diagram
This page shows the only wiring diagram for the component.trac on/off switch, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trac on/off switch (1 of 1)
14 27 AWD CTRL CLASS 2
3.4L
3.6L
74 58 AWD CTRL CLASS 2
AWD FUSE 30
BLK WIRE
BODY CONTROL MODULE (IN CONSOLE, ABOVE FUSE BLOCK, IN CENTER CONSOLE)
BRN/WHT WIRE
CLASS 2
DIFFERENTIAL CLUTCH PUMP ACTUATOR CHECK VALVE
DK GRN WIRE
ELECTRONIC BRAKE CONTROL MODULE (EBCM) (LEFT SIDE OF ENGINE COMPT)
ENGINE CONTROL MODULE (ECM)
GRN WIRE
HOT IN RUN OR START
I/P SWITCH ASSEMBLY
LT BLU WIRE
LT GRN WIRE
NAVIGATION SYSTEM
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PPL
PPL DATA LINK CONNECTOR (PARTIAL) (BELOW STEERING COLUMN)
TCS MODC
TRAC ON/OFF SWITCH
TRANSMISSION CONTROL MODULE (TCM) (3.6L) (INSIDE AIR CLEANER ASSEMBLY)
UNDERHOOD FUSE BLOCK (FRONT OF RIGHT WHEELHOUSE, ABOVE BATTERY)
YEL WIRE
Go to component -> Rear differential lock circuit -> TRAC ON/OFF SWITCH
