Buick Rendezvous I (2001-2007) tcc 2-3 shift sol pwm sol Wiring diagram

A/T FLUID PRESSURE MANUAL VALVE POSITION SWITCH AUTOMATIC TRANSAXLE AUTOMATIC TRANSAXLE FLUID TEMPERATURE SENSOR AUTOMATIC TRANSAXLE INPUT SHAFT SPEED SENSOR 1-2 SHIFT SOL BLK WIRE BLK/WHT WIRE BRN WIRE BRN/WHT WIRE BUICK PONTIAC CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE) DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ENGINE COOLANT TEMPERATURE (ECT) SENSOR GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACCY, RUN, OR START HOT IN RUN OR START IGN IGN 0 IGN 0 FUSE 30 IGN 1 MAIN FUSE 27 INSTRUMENT PANEL CLUSTER INTEMM FUSE 24 LT BLU/WHT WIRE LT GRN WIRE MALFUNCTION INDICATOR LAMP MANIFOLD ABSOLUTE PRESSURE (MAP) SENSOR (ON TOP FRONT OF ENGINE) ORG/ WIRE ORG/BLK WIRE PNK WIRE PNK/WHT WIRE PPL PPL DATA LINK CONNECTOR (PARTIAL) (BELOW STEERING COLUMN) PRESSURE CONTROL SOL VALVE RED WIRE RED/BLK WIRE STOPLIGHT SWITCH (ON BRAKE PEDAL SUPPORT) TAN WIRE TCC 2-3 SHIFT SOL PWM SOL TCC/ BRAKE SWITCH THROTTLE POSITION (TP) SENSOR (TOP OF ENGINE) TRANS SOL FUSE 7 TRANSAXLE INTERNAL MODE SWITCH (IMS) UNDERHOOD FUSE BLOCK (FRONT OF RIGHT WHEELHOUSE, ABOVE BATTERY) PCM FUSE 5 VEHICLE SPEED SENSOR (VSS) (ON TRANSAXLE) WHT WIRE YEL WIRE YEL/BLK WIRE
