Buick Rendezvous I (2001-2007) sun rf fuse 34 Wiring diagram
This page shows the only wiring diagram for the component.sun rf fuse 34, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sun rf fuse 34 (1 of 1)
1 2 3 4 5 6 7 8 LOW REF RANGE SIG
BLK WIRE
BRN WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
CLOSE
CLOSE BATTERY OPEN GROUND
CONNECTOR
DK BLU WIRE
DK GRN WIRE
HOT W/ RAP RELAY ENERGIZED
LIMIT SWITCHES
LOW REF OPEN CLOSE SOFT STOP SIG
NCA WIRE
OPEN/ VENT
ORG/ WIRE
RANGE
RED WIRE
SOFT STOP
SUN RF FUSE 34
SUNROOF MODULE
SUNROOF MOTOR (FRONT OF SUNROOF ASSEMBLY)
SUNROOF POSITION ENCODING SWITCH
SUNROOF SWITCH
YEL WIRE
Go to component -> Power top/sunroof circuit -> SUN RF FUSE 34
