Buick Rendezvous I (2001-2007) sir fuse 22 Wiring diagrams
This page contains all the electrical diagrams for the component. sir fuse 22, in which he is found in the car Buick Rendezvous I (2001-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
sir fuse 22 wiring diagram (1 of 2)
AOS FUSE 46
AUTOMATIC A/C MANUAL A/C
BACKUP LPS RELAY 45
BCM- ACCY FUSE 44 IGN 1 MDL FUSE 18 ACCY DIODE 43
BLK WIRE
BLWR FUSE 25
BRN WIRE
CENTER CONSOLE FUSE BLOCK
CENTER CONSOLE FUSE BLOCK (IN FLOOR
CONSOLE)
DK GRN WIRE
FROM BATT 3 FUSE 41 (DIAGRAM 1 OF 4)
FROM IGN 3 FUSE 19 (DIAGRAM 1 OF 4)
FROM IGN 3 FUSE 46 (DIAGRAM 1 OF 4)
FROM INKEY FUSE 42 (DIAGRAM 1 OF 4)
HEAD UP DISPLAY (HUD) (IF EQUIPPED)
HTD MIRR FUSE 16
HVAC CONTROL MODULE
IGN 0 FUSE 30
IGN 3 HVAC FUSE 26
IGN 3 RELAY 23
IGNITION SWITCH
INFLATABLE RESTRAINT PASSENGER PRESENCE MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (SDM)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT AIR TEMPERATURE ACTUATOR
LOCK OFF
LT GRN WIRE
MANUAL A/C
MIRROR
MODE ACTUATOR
NCA WIRE
ORG/ WIRE
PNK PNK PNK WIRE
PNK W/ POWER HEATED FOLDING MIRRORS WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
PPL
PPL PPL
REAR DEFOG RELAY 20
REAR PARKING ASSIST (RPA) MODULE LIFTGATE LAMP ASSEMBLY
REAR WINDOW DEFOGGER
RECIRCULATION ACTUATOR I/P SWITCH ASSEMBLY (W/ PARKING ASSIST)
RED WIRE
RIGHT AIR TEMPERATURE ACTUATOR
RR DEF FUSE 21
RUN WIRE
SIR FUSE 22
SPLICE
THEFT THEFT DETERRENT CONTROL MODULE BODY CONTROL MODULE (BCM)
TO ACCY RELAY (DIAGRAM 1 OF 4)
TO IGN 1 MAIN FUSE 27 (DIAGRAM 2 OF 4)
TRN SIG FUSE INTEMM FUSE 24
TURN SIGNAL/ HAZARD FLASHER SWITCH STOPLAMP SWITCH INSIDE REARVIEW
YEL WIRE
Go to component -> Power distribution circuit (3 of 4) -> SIR FUSE 22
sir fuse 22 wiring diagram (2 of 2)
5 6 PNK WIRE
BLK WIRE
BLK/WHT WIRE
BREAKOUT)
BRN WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
CLASS 2 SERIAL DATA LEFT SEAT BELT SWITCH
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT BELT SWITCH (IN RIGHT HALF OF DRIVER SEAT BELT)
GRY WIRE
HOT IN ON OR START
INFLATABLE RESTRAINT I/P MODULE (RIGHT SIDE OF DASH, ABOVE GLOVE BOX)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER RIGHT FRONT SEAT)
LEFT INFLATABLE RESTRAINT SIDE IMPACT MODULE
LEFT SEAT BELT PRETENSIONER
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER SEAT BELT SWITCH (IN RIGHT HALF OF DRIVER
PNK/WHT WIRE
PPL
RED WIRE
RIGHT INFLATABLE RESTRAINT SIDE IMPACT MODULE
RIGHT SEAT BELT PRETENSIONER
RIGHT SEAT BELT SWITCH
SEAT BELT
SHORTING BAR
SIR FUSE 22
TAN WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> SIR FUSE 22
