Buick Rendezvous I (2001-2007) service traction system ind Wiring diagram

3.6L 3.4L 9 8 37 5 DEL TORQUE ENGINE SPD ABS FUSE 6 ABS IND IGN 0 ABS MTR MAXI FUSE 36 ABS VLV FUSE 9 ASSEMBLY BLK WIRE BLK/WHT WIRE BODY CONTROL MODULE (IN CONSOLE, ABOVE FUSE BLOCK, IN CENTER CONSOLE) BRAKE FLUID LEVEL SWITCH (ON RIGHT SIDE OF BRAKE FLUID RESERVOIR) BRN WIRE BRN/WHT WIRE CENTER CONSOLE FUSE BLOCK (IN FLOR CONSOLE) COMPUTER DATA LINES SYSTEM CRUISE CONTROL MODULE (AT LEFT SIDE OF ENGINE COMPT, NEAR STRUT TOWER) DATA LINK CONNECTOR (BELOW STEERING COLUMN) DK GRN WIRE ELECTRONIC BRAKE CONTROL MODULE (EBCM) ENG SPD SIG PUMP GND B+ B+ GND GRY WIRE HOT AT ALL TIMES HOT IN ACC, RUN OR START HOT IN RUN OR START HZD FL FUSE 40 I/P SWITCH ASSEMBLY IGN 0 FUSE 30 INSTRUMENT PANEL CLUSTER (IPC) LEFT FRONT WHEEL SPEED SENSOR (WSS) LEFT REAR WHEEL SPEED SENSOR LF WHL SPD LF WHL SPD LR WHL SPD LR WHL SPD LOGIC LT BLU WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PARK BRAKE SWITCH (ON PARK BRAKE PNK IGNITION DEL TORQUE SIG WIRE PNK WIRE PPL PUMP MOTOR RED WIRE REQ TORQUE REQ TORQUE SIG RIGHT FRONT WHEEL SPEED SENSOR (WSS) RIGHT REAR WHEEL SPEED SENSOR (WSS) RR WHL SPD RR WHL SPD RF WHL SPD RF WHL SPD STOP LP SW SERIAL DATA SERIAL DATA BRAKE IND SERVICE TRACTION SYSTEM IND SPLICE PACK STOPLIGHT SWITCH (ON BRAKE PEDAL SUPPORT) SW SIG TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TRAC OFF IND TRAC OFF SWITCH TRAC SW TRACTION ACTIVE IND UNDERHOOD FUSE BLOCK (FRONT OF RIGHT WHEELHOUSE, ABOVE BATTERY) W/ TRACTION CONTROL WHT WIRE YEL WIRE
