Buick Rendezvous I (2001-2007) rear window washer pump cntrl Wiring diagram
This page shows the only wiring diagram for the component.rear window washer pump cntrl, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window washer pump cntrl (1 of 1)
BLK WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
DK GRN WIRE
GRY WIRE
HOT IN ACC OR RUN
I/P SWITCH ASSEMBLY REAR WIPER/ WASHER SWITCH
LOGIC ACCESSORY VOLTAGE
PARK
REAR WINDOW WASHER FLUID PUMP
REAR WINDOW WASHER PUMP CNTRL
REAR WINDOW WIPER MOTOR (IN TAILGATE)
REAR WINDOW WIPER MOTOR CNTRL
REAR WINDOW WIPER SWITCH SIGNAL
RRWPR FUSE 32
RUN WIRE
SPLICE PACK
WASH
WIPE
WIPER ARM POSITION SIGNAL
YEL WIRE
Go to component -> Rear wiper/washer circuit -> REAR WINDOW WASHER PUMP CNTRL
