Buick Rendezvous I (2001-2007) rear window washer fluid pump Wiring diagrams

6 SPEAKER ACCY RELAY 27 AUXILIARY DROP CONNECTOR BLK WIRE BLOWER MOTOR CONTROL PROCESSOR BLOWER MOTOR RESISTOR ASSEMBLY BODY CONTROL MODULE (BCM) BRAKE FLUID LEVEL SWITCH CIGAR LIGHTER CONSOLE AUXILIARY POWER OUTLET CONSOLE COMPARTMENT LAMP DATA LINK CONNECTOR (DLC) DIGITAL RADIO RECEIVER DRIVER INFORMATION CENTER (DIC) SWITCH FLASHER 10 HEAD- LAMP SWITCH HVAC CONTROL MODULE HVAC SYSTEM AIR COND FRONT MANUAL HVAC SYSTEM AIR COND. FRT, AUTO TEMP CONT, AUX TEMP CONTROL I/P SWITCH ASSEMBLY IGNITION COIL 1 IGNITION COIL 3 IGNITION COIL 5 INSTRUMENT PANEL CLUSTER (IPC) KEY-IN IGNITION SWITCH LEFT AIR TEMPERATURE ACTUATOR MODE ACTUATOR RADIO RAP RELAY 33 IGN 3 RELAY 23 REAR SEAT AUDIO REAR SEAT ENTER- TAINMENT ASSEMBLY REAR WINDOW WASHER FLUID PUMP RECIR- CULATION ACTUATOR REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) RIGHT AIR TEMPERATURE ACTUATOR SPLICE PACK THEFT DETERRENT CONTROL MODULE TURN SIGNAL/ HAZARD FLASHER SWITCH VEHICLE COMMUNICATION INTERFACE MODULE (VCIM) W/ OBSTACLE PRESENCE DETECTION W/ TRACTION CONTROL WHT WIRE WINDSHIELD WASHER FLUID LEVEL SWITCH WINDSHIELD WASHER FLUID PUMP WINDSHIELD WIPER MOTOR

BLK WIRE CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE) DK GRN WIRE GRY WIRE HOT IN ACC OR RUN I/P SWITCH ASSEMBLY REAR WIPER/ WASHER SWITCH LOGIC ACCESSORY VOLTAGE PARK REAR WINDOW WASHER FLUID PUMP REAR WINDOW WASHER PUMP CNTRL REAR WINDOW WIPER MOTOR (IN TAILGATE) REAR WINDOW WIPER MOTOR CNTRL REAR WINDOW WIPER SWITCH SIGNAL RRWPR FUSE 32 RUN WIRE SPLICE PACK WASH WIPE WIPER ARM POSITION SIGNAL YEL WIRE
