Buick Rendezvous I (2001-2007) rear vert- ical motor Wiring diagram
This page shows the only wiring diagram for the component.rear vert- ical motor, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear vert- ical motor (1 of 1)
AFT FRT UP
BACK FRT UP
BLK WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER SWITCH
FORE- HORI- ZONTAL MOTOR FRONT VERT- ICAL MOTOR
FORE/
FRONT PASSENGER SEAT ADJUSTER MOTOR ASSEMBLY
FRONT PASSENGER SEAT ADJUSTER SWITCH
FRONT VERT- ICAL MOTOR
FRT
HORI- ZONTAL MOTOR
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PWR STS CIRCUIT BREAKER
REAR VERT- ICAL MOTOR
RR DN
RR UP FRT DN
TAN WIRE
YEL WIRE
Go to component -> 6-way power seat circuit -> REAR VERT- ICAL MOTOR
