Buick Rendezvous I (2001-2007) passenger seat belt switch (in right half of driver wiring diagram
This page shows the only wiring diagram for the component.passenger seat belt switch (in right half of driver, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
passenger seat belt switch (in right half of driver wiring diagram (1 of 1)
5 6 PNK WIRE
BLK WIRE
BLK/WHT WIRE
BREAKOUT)
BRN WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
CLASS 2 SERIAL DATA LEFT SEAT BELT SWITCH
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT BELT SWITCH (IN RIGHT HALF OF DRIVER SEAT BELT)
GRY WIRE
HOT IN ON OR START
INFLATABLE RESTRAINT I/P MODULE (RIGHT SIDE OF DASH, ABOVE GLOVE BOX)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER RIGHT FRONT SEAT)
LEFT INFLATABLE RESTRAINT SIDE IMPACT MODULE
LEFT SEAT BELT PRETENSIONER
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
PASSENGER SEAT BELT SWITCH (IN RIGHT HALF OF DRIVER
PNK/WHT WIRE
PPL
RED WIRE
RIGHT INFLATABLE RESTRAINT SIDE IMPACT MODULE
RIGHT SEAT BELT PRETENSIONER
RIGHT SEAT BELT SWITCH
SEAT BELT
SHORTING BAR
SIR FUSE 22
TAN WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> PASSENGER SEAT BELT SWITCH (IN RIGHT HALF OF DRIVER
