Buick Rendezvous I (2001-2007) park lps fuse 20 fog lps fuse 26 Wiring diagram
This page shows the only wiring diagram for the component.park lps fuse 20 fog lps fuse 26, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park lps fuse 20 fog lps fuse 26 (1 of 1)
3.6L
ABS MTR FUSE 35
ABS SOL FUSE 9
ACCY RELAY 27
AUTOMATIC A/C MANUAL A/C
AUXILIARY DROP CONNECTOR
BATT 1 FUSE 47
BATT 2 FUSE 44 BATT 3 FUSE 41
BATTERY
BCM FUSE 28
BLK WIRE
BLOWER MOTOR RESISTOR ASSEMBLY BLOWER MOTOR CONTROL PROCESSOR
BODY CONTROL MODULE
BODY CONTROL MODULE (BCM)
CENTER CONSOLE AUXILIARY POWER OUTLET
CIGAR LIGHTER
CONTROL MODULE (ECM)
COOL FAN 1 FUSE 39 A/C CLU FUSE 2
COOL FAN 1 RELAY 61 COOL FAN 2 RELAY 60 A/C CLU RELAY 51
COOL FAN 2 FUSE 38
COOL FAN S/P RELAY 58 CRANK RELAY 57
DATA LINK CONNECTOR (DLC)
DIGITAL RADIO RECEIVER
DVD FUSE 25
EARLY PRODUCTION
ECM PCM FUSE 5 (3.6L) (3.4L)
ELC ACCY FUSE 15 SUN RF FUSE 34 PWR FUSE 28
ELECTRONIC BRAKE CONTROL MODULE (EBCM)
EVAPORATIVE EMISSION (EVAP) CANISTER VENT SOLENOID
FOG LPS RELAY 56 HORN RELAY PARK LPS RELAY 54
FROM ACCY DIODE (DIAGRAM 3 OF 4)
FROM IGN 3 FUSE 19 (DIAGRAM 1 OF 4)
FRONT PASSENGER WINDOW SWITCH
FRT AUX FUSE 32
FUEL PUMP FUSE 1
FUEL PUMP RELAY 50
FUSIBLE LINK
GENERATOR
HDLP LO BEAM RELAY 54 (DIAGRAM 2 OF 4)
HORN FUSE 3
IGN 1 FUSE 40 IGN 3 FUSE 46
IGN 1/ IGN 3 FUSE 19
INKEY FUSE 42
LATE PRODUCTION
ORG/ WIRE
PARK LPS FUSE 20 FOG LPS FUSE 26
POWERTRAIN CONTROL MODULE (PCM)/ ENGINE
PWR WDWS CIRCUIT BREAKER 35 HZD FL FUSE 40 BCML FUSE 36
RAP RELAY
RD AMP FUSE 38 HUD FUSE 39 RADIO FUSE 37
REAR SEAT ENTER- TAINMENT (RSE) ASSEMBLY
RED WIRE
RR WPR FUSE 32
S- BAND FUSE 29
SPLICE
STARTER
STRTR SOL FUSE 34
SUNROOF AUTOMATIC LEVEL CONTROL MODULE (ALC) SENSOR (IF EQUIPPED) (IF EQUIPPED)
TCM FUSE 8
THEFT DETERRENT CONTROL MODULE
TO BATT 1 FUSE 47 (DIAGRAM 1 OF 4)
TO IGN 3 RELAY (DIAGRAM 3 OF 4)
TO IGNITION SWITCH PIN B (DIAGRAM 3 OF 4
TO IGNITION SWITCH PIN F (DIAGRAM 3 OF 4)
TO REAR DEFOG RELAY 20 (DIAGRAM 3 OF 4) TO RR AUX FUSE 14 (DIAGRAM 4 OF 4)
TRANSMISSION CONTROL MODULE
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
VENT SOL FUSE 24
WINDOW MASTER SWITCH STOPLAMP SWITCH
WINDSHIELD WIPER MOTOR I/P SWITCH ASSEMBLY REAR WINDOW WIPER MOTOR
WIPER FUSE 29
YEL WIRE
Go to component -> Power distribution circuit (1 of 4) -> PARK LPS FUSE 20 FOG LPS FUSE 26
