Buick Rendezvous I (2001-2007) memory seat, mirror switch window master switch Wiring diagram
This page shows the only wiring diagram for the component.memory seat, mirror switch window master switch, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram memory seat, mirror switch window master switch (1 of 1)
3.6L
BLK WIRE
BREAKOUT)
BRN WIRE
CARGO LAMP
CENTER CONSOLE FUSE BLOCK
DRIVER DOOR LATCH
DRIVER DOOR LOCK CYLINDER SWITCH DRIVER OUTSIDE REAR VIEW MIRROR
DRIVER DOOR LOCK SWITCH
DRIVER HEATED SEAT ELEMENT (BACK)
DRIVER HEATED SEAT MODULE
DRIVER HEATED SEAT THERMISTOR
DRIVER SEAT ADJUSTER SWITCH LEFT REAR DOOR LATCH
FUEL PUMP, SENDER ASSEMBLY
GARAGE DOOR OPENER
IGNITION COIL 2
IGNITION COIL 4
IGNITION COIL 6
INSIDE REAR VIEW MIRROR
LEFT ROOF RAIL READING LAMP
LEFT VANITY MIRROR
MEMORY SEAT, MIRROR MODULE
MEMORY SEAT, MIRROR SWITCH WINDOW MASTER SWITCH
NCA WIRE
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
RIGHT REAR MARKER LAMP
RIGHT REAR PARK/ STOP/ TURN SIGNAL LAMP
RIGHT ROOF RAIL READING LAMP
RIGHT VANITY MIRROR
SEAT BELT SWITCH
W/ HEATED SEATS
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (3 of 4) -> MEMORY SEAT, MIRROR SWITCH WINDOW MASTER SWITCH
