Buick Rendezvous I (2001-2007) memory seat, mirror switch Wiring diagrams
This page contains all the electrical diagrams for the component. memory seat, mirror switch, in which he is found in the car Buick Rendezvous I (2001-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram memory seat, mirror switch (1 of 2)
Go to component -> Instrument illumination circuit (2 of 2) -> MEMORY SEAT, MIRROR SWITCH
Wiring diagram memory seat, mirror switch (2 of 2)
AFT
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
CLASS 2 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DR ST HORI POS SEN DR ST RR VERT POS SEN DR ST FRT VERT POS SEN
DRIVER OUTSIDE REARVIEW MIRROR
DRIVER SEAT ADJUSTER MOTOR ASSEMBLY
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT POSITION SENSOR
EXIT MEM 1
FORE/
FRONT UP/DOWN
FRONT VERTICAL
FRT DN
FRT UP
GND BAT (+)
GRY WIRE
HORI- ZONTAL
HORIZONTAL FOR/AFT
HOT AT ALL TIMES
LEFT
LOW REF
LT BLU WIRE
LT BLU/BLK WIRE
LT GRN WIRE
LT MIR HOR POS SEN LT MIR VER POS SEN RT MIR HOR POS SEN RT MIR VER POS SEN
LT MIR MTR RT CTRL LT MIR MTR LT CTRL LT MIR MTR DN CTRL
LT RT
MEM 2
MEMORY 2 SW SIG MEMORY 1 SW SIG
MEMORY SEAT, MIRROR MODULE (UNDER DRIVER SEAT)
MEMORY SEAT, MIRROR SWITCH
MIR SW PWR DR SEAT SW PWR
NCA WIRE
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PASSENGER OUTSIDE REARVIEW MIRROR
PPL
PPL 616 615
PPL/WHT WIRE
PWR STS CIRCUIT BREAKER 11
REAR UP/DOWN
REAR VERTICAL
RED/DK BLU WIRE
RED/DK GRN WIRE
RED/WHT WIRE
RR DN
RR UP
RT MIR MTR RT CTRL RT MIR MTR LT CTRL RT MIR MTR DN CTRL
TAN WIRE
VERTICAL
WHT WIRE
YEL WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/WHT WIRE
Go to component -> Memory seat & mirrors circuit -> MEMORY SEAT, MIRROR SWITCH
