Buick Rendezvous I (2001-2007) lt mir hor pos sen lt mir ver pos sen rt mir hor pos sen rt mir ver pos sen Wiring diagram

AFT BLK WIRE BRN WIRE BRN/WHT WIRE CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE) CLASS 2 SERIAL DATA COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DR ST HORI POS SEN DR ST RR VERT POS SEN DR ST FRT VERT POS SEN DRIVER OUTSIDE REARVIEW MIRROR DRIVER SEAT ADJUSTER MOTOR ASSEMBLY DRIVER SEAT ADJUSTER SWITCH DRIVER SEAT POSITION SENSOR EXIT MEM 1 FORE/ FRONT UP/DOWN FRONT VERTICAL FRT DN FRT UP GND BAT (+) GRY WIRE HORI- ZONTAL HORIZONTAL FOR/AFT HOT AT ALL TIMES LEFT LOW REF LT BLU WIRE LT BLU/BLK WIRE LT GRN WIRE LT MIR HOR POS SEN LT MIR VER POS SEN RT MIR HOR POS SEN RT MIR VER POS SEN LT MIR MTR RT CTRL LT MIR MTR LT CTRL LT MIR MTR DN CTRL LT RT MEM 2 MEMORY 2 SW SIG MEMORY 1 SW SIG MEMORY SEAT, MIRROR MODULE (UNDER DRIVER SEAT) MEMORY SEAT, MIRROR SWITCH MIR SW PWR DR SEAT SW PWR NCA WIRE ORG/ WIRE OUTSIDE REARVIEW MIRROR SWITCH PASSENGER OUTSIDE REARVIEW MIRROR PPL PPL 616 615 PPL/WHT WIRE PWR STS CIRCUIT BREAKER 11 REAR UP/DOWN REAR VERTICAL RED/DK BLU WIRE RED/DK GRN WIRE RED/WHT WIRE RR DN RR UP RT MIR MTR RT CTRL RT MIR MTR LT CTRL RT MIR MTR DN CTRL TAN WIRE VERTICAL WHT WIRE YEL WIRE YEL/DK BLU WIRE YEL/DK GRN WIRE YEL/WHT WIRE
