Buick Rendezvous I (2001-2007) low washer fluid ind sig Wiring diagram
This page shows the only wiring diagram for the component.low washer fluid ind sig, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low washer fluid ind sig (1 of 1)
BLK WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
DELAY
DK GRN WIRE
GROUND
GRY WIRE
HI LO
HI MIST
HI MIST LO OFF DELAY
HOT IN ACC OR RUN
IGN
IND CTRL
INSTRUMENT PANEL CLUSTER (IPC) LOGIC
LO OFF
LOW WASHER FLUID
LOW WASHER FLUID IND SIG
MIST
OFF
PPL
RED WIRE
SPLICE PACK
TAN WIRE
TURN SIGNAL/MULTI-FUNCTION SWITCH
WASHER SWITCH
WINDSHIELD WASHER FLUID LEVEL SWITCH (ON FRONT WASHER SOLVENT CONTAINER)
WINDSHIELD WASHER FLUID PUMP (ON FRONT WASHER SOLVENT CONTAINER)
WINDSHIELD WIPER MOTOR (AT RIGHT REAR OF ENGINE COMPARTMENT) ACCESSORY VOLTAGE
WIPER FUSE
WIPER SWITCH
YEL WIRE
