Buick Rendezvous I (2001-2007) low sensitivity setting high sensitivity setting wiring diagram
This page shows the only wiring diagram for the component.low sensitivity setting high sensitivity setting, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
low sensitivity setting high sensitivity setting wiring diagram (1 of 1)
AMBIENT LIGHT SENSOR
AUTOMATIC DAY-NIGHT MIRROR ELEMENT
BACKUP LAMP SUPPLY VOLTAGE
BACKUP LPS RELAY
BLK WIRE
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
CONNECTOR
GRY WIRE
HEADLIGHT SENSOR
HOT IN RETAINED ACCESSORY POWER
HOT IN RUN OR START
INSIDE REARVIEW MIRROR
LOGIC
LOW REFERENCE SIGNAL
LOW SENSITIVITY SETTING HIGH SENSITIVITY SETTING
LT GRN WIRE
NAVIGATION SYSTEM
OFF MAX MIN
ORG/ WIRE
POWER TOPS SYSTEM
SUN RF FUSE
TURN SIG FUSE
YEL WIRE
Go to component -> Electrochromic mirror circuit -> LOW SENSITIVITY SETTING HIGH SENSITIVITY SETTING
