Buick Rendezvous I (2001-2007) liftgate release switch signal Wiring diagram
This page shows the only wiring diagram for the component.liftgate release switch signal, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate release switch signal (1 of 1)
BATTERY
BLK WIRE
BODY CONTROL MODULE (IN CONSOLE, ABOVE FUSE BLOCK, IN CENTER CONSOLE)
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
DK BLU WIRE
ENDGATE LOCK CYLINDER SWITCH
GATE REL FUSE 13
GRY WIRE
HOT AT ALL TIMES
I/P SWITCH ASSEMBLY
LEFT ENDGATE LOCK ACTUATOR (LEFT SIDE OF TAILGATE)
LEFT LIFT WINDOW LOCK ACTUATOR
LIFT GLASS RELEASE CONTROL
LIFTGATE LOCK ACTUATOR (IN TAILGATE)
LIFTGATE RELEASE SWITCH SIGNAL
LIFTGATE/ENDGATE LOCK MOTOR LOCK CONTROL
LIFTGATE/ENDGATE LOCK MOTOR UNLOCK CONTROL
LT BLU WIRE
ORG/ WIRE
PONTIAC
PPL
RED WIRE
RIGHT ENDGATE LOCK ACTUATOR (RIGHT SIDE OF TAILGATE)
RIGHT LIFT WINDOW LOCK ACTUATOR
TOUCH PAD SWITCH
WHT WIRE
WHT/BLK WIRE
Go to component -> Liftgate release circuit -> LIFTGATE RELEASE SWITCH SIGNAL
