Buick Rendezvous I (2001-2007) exterior lights system dk Wiring diagram
This page shows the only wiring diagram for the component.exterior lights system dk, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram exterior lights system dk (1 of 1)
BATTERY
BCM BCME FUSE 28 (BUICK) (PONTIAC)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
DATA
DK BLU WIRE
DRIVER DOOR LATCH (IN DRIVER'S DOOR)
DRIVER INFORMATION CENTER (DIC) DISPLAY
DRIVER SEAT BELT SWITCH (OPENS WHEN BUCKLED)
EXTERIOR LIGHTS SYSTEM DK
GRY WIRE
HEAD
HEADLAMP SWITCH
HOT AT ALL TIMES UNDERHOOD FUSE BLOCK (FRONT OF RIGHT WHEELHOUSE, ABOVE BATTERY)
IGN
IGNITION KEY ALARM SWITCH (CLOSED W/ KEY IN IGNITION)
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER RIGHT FRONT SEAT)
KEY IN IGN SW
LOGIC INSTRUMENT PANEL CLUSTER (IPC)
LT BLU WIRE
LT GRN WIRE
MESSAGE CENTER IPC
NCA WIRE
OFF
ORG/ WIRE
PARK
PARK LAMPS SIGNAL
RADIO
REAR PARK CHIME DRIVER DOOR OPEN
RIGHT TURN LEFT TURN
SEAT BELT IND LOGIC
SERIAL DATA
SERIAL DATA LEFT SEAT BELT SW
STEERING COLUMN)
TAN WIRE
Go to component -> Warning systems circuit -> EXTERIOR LIGHTS SYSTEM DK
