Buick Rendezvous I (2001-2007) camshaft position sensor intake bank 1 Wiring diagram
This page shows the only wiring diagram for the component.camshaft position sensor intake bank 1, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camshaft position sensor intake bank 1 (1 of 1)
23 24 25 26 27 28 PPL
BAROMETRIC PRESSURE (BARO) SENSOR
BLK WIRE
BRN WIRE
CAMSHAFT POSITION ACTUATOR SOLENOID (EXHAUST BANK 1)
CAMSHAFT POSITION ACTUATOR SOLENOID (EXHAUST BANK 2)
CAMSHAFT POSITION ACTUATOR SOLENOID (INTAKE BANK 1)
CAMSHAFT POSITION ACTUATOR SOLENOID (INTAKE BANK 2)
CAMSHAFT POSITION SENSOR EXHAUST BANK 1
CAMSHAFT POSITION SENSOR EXHAUST BANK 2
CAMSHAFT POSITION SENSOR INTAKE BANK 1
CAMSHAFT POSITION SENSOR INTAKE BANK 2
DK GRN WIRE
DK GRN/WHT WIRE
EVAPORATIVE EMISSIONS (EVAP) CANISTER PURGE
GRY WIRE
IAT SENSOR
LOW REF
LT GRN WIRE
MAF SENSOR
ORG/ WIRE
ORG/BLK WIRE
PNK WIRE
PNK/BLK WIRE
PPL
SIGNAL
SOLENOID VALVE (ON TOP RIGHT REAR OF ENGINE, NEAR THROTTLE BODY)
TAN WIRE
THROTTLE BODY ASSEMBLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.6l vin 7 (3 of 4) -> CAMSHAFT POSITION SENSOR INTAKE BANK 1
