Buick Rendezvous I (2001-2007) (body harness, under left rear of vehicle, Wiring diagram
This page shows the only wiring diagram for the component.(body harness, under left rear of vehicle,, which is found in the car Buick Rendezvous I (2001-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram (body harness, under left rear of vehicle, (1 of 1)
AUTOMATIC A/C MANUAL A/C
AUTOMATIC LEVEL CONTROL (ALC) COMPRESSOR
AUTOMATIC LEVEL CONTROL (ALC) INFLATOR AIR SWITCH
AUTOMATIC LEVEL CONTROL (ALC) SENSOR
BCM D FUSE 3
BLK WIRE
BODY CONTROL MODULE (BCM)
CENTER CONSOLE FUSE BLOCK (IN FLOOR CONSOLE)
DRIVER HEATED SEAT MODULE
DRIVER POSITIVE TEMPERATURE COEFFICIENT (PTC) CIRCUIT BREAKER
DRIVER SEAT ADJUSTER SWITCH
ELC BATT FUSE 12
FROM BATT 2 FUSE 44 (DIAGRAM 1 OF 4)
FROM BCM L FUSE 36 (DIAGRAM 1 OF 4)
FRONT PASSENGER HEATED SEAT MODULE FRONT PASSENGER SEAT ADJUSTER SWITCH
FRONT PASSENGER POSITIVE TEMPERATURE COEFFICIENT (PTC) CIRCUIT BREAKER
GARAGE DOOR OPENER
GATE REL FUSE 13
HVAC CONTROL MODULE
INSTRUMENT PANEL CLUSTER (IPC)
IP MDL FUSE 41
MEMORY SEAT, MIRROR MODULE AUTOMATIC LEVEL CONTROL (ALC) COMPRESSOR RELAY
ORG/ WIRE
OUTSIDE REARVIEW MIRROR SWITCH
PWR MIR FUSE 17
PWR STS CIRCUIT BREAKER
REAR AUXILIARY POWER OUTLET
RED WIRE
REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR)
RR AUX FUSE 14
SECURITY INDICATOR LAMP
SPLICE PACK
TRAILER WIRING HARNESS (BLUNT CUT)
W/ AUTOMATIC LEVEL CONTROL
W/ MEMORY SEAT
W/ TRAILER PROVISIONS
W/O MEMORY SEAT
Go to component -> Power distribution circuit (4 of 4) -> (BODY HARNESS, UNDER LEFT REAR OF VEHICLE,
