Buick Regal VI (2017-2020) rh side object detc led ctrl wiring diagram
This page shows the only wiring diagram for the component.rh side object detc led ctrl, which is found in the car Buick Regal VI (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rh side object detc led ctrl wiring diagram (1 of 1)
BATT POSI VOLT
BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SIDE OBJECT DETECTION INDICATOR
FUSE 40
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HI SPD GMLAN SER DATA (+) 5
HOT W/ BATTERY SAVER RELAY 1 ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LEFT SIDE OBJECT SENSOR MODULE
LH SIDE OBJECT DETC LED CTRL
LO SPD GMLAN SER DATA
LO SPD GMLAN SER DATA 2
LOGIC
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER SIDE OBJECT DETECTION INDICATOR
RED WIRE
RED/GRN WIRE
RH SIDE OBJECT DETC LED CTRL
RIGHT SIDE OBJECT SENSOR MODULE
YEL WIRE
Go to component -> Blind spot monitoring circuit -> RH SIDE OBJECT DETC LED CTRL
